12V 200Ah Solar Panel Powered / Solar LiFePO4 Battery 12V 200Ah

Premium LiFePO₄ battery packs engineered for solar energy storage and backup. Available in modular formats (example: 12V 200Ah - 2.56 kWh per pack), these units deliver long life (>6,000 cycles), low self-discharge, wide temperature tolerance, and comprehensive protection via an integrated BMS. Ideal for residential PV, off-grid cabins, commercial lighting and UPS applications.

Configuration parameters

Warranty:10YEARS

Place of Origin:Shandong, China

Brand Name:Blue Carbon

Battery Type:Lithium Ion

Output Voltage (V):12.8V

Certificate Standards:CE/UN38.3/MSDS/DGM

Model:BCT-UU 12-200

Battery:Lithium LiFePO4

Rated Voltage:12.8V

Capacity:200Ah

Continuously Use Input/Output Current:100A

Input Voltage Range:14V-15V

Maximum Charging Voltage:15V

Self-discharge (25°C):<3%/month

Depth of Discharge:>80%

Operating Temperature Range:-15°C-60°C

Recommended Temperature range:10℃--40℃

Key Benefits

• Long lifecycle: >6,000 cycles for lower replacement cost.
• High usable capacity: >80% DoD for maximum stored energy use.
• Fast charge/discharge: supports high C-rates for peak demand use cases.
• Safe & robust: multi-layer protection and non-toxic materials.
• Low self-discharge: <3%/month at 25°C.
•

FAQ

Q: How long will a 12V/200Ah LFP battery last?
A: Typical cycle life is >6,000 cycles under recommended conditions; real calendar life depends on usage and environment.

UU 12V-200Ah LiFePO4 Battery Pa…

Q: Can I connect multiple packs in series/parallel?
A: Yes - but follow datasheet rules (max series/parallel counts) and ensure consistent voltages and proper charge controllers.

UU 12V-200Ah LiFePO4 Battery Pa…

Q: Do I need a special MPPT?
A: Use MPPT controllers with LFP mode. When using high-voltage MPPT, ensure the circuit has high-voltage isolation and charging protection.
