Blue Carbon High Quality Good Price 48V 200Ah LiFePO4 Battery
Discover the future of solar energy storage with our 48V cast-aluminum LiFePO4 battery, a game-changer in renewable energy.
Crafted using high-grade cast aluminum, our battery ensures exceptional strength and durability, protecting it against the elements and providing a long lifespan. The LiFePO4 chemistry within the cells offers excellent thermal stability, intrinsic safety, and outstanding cycle life, making it an ideal choice for solar energy storage applications.
Our solar energy storage solution includes an intelligent BMS that actively monitors the battery's status, ensuring optimal performance and protecting against overcharging, over-discharging, and short circuits. By regulating the battery's parameters, the BMS enhances its lifespan and ensures efficient energy utilization, maximizing the return on your solar investment.
The intelligent BMS continuously monitors the battery's status, optimizing charging and discharging cycles, protecting against voltage imbalances, and providing real-time diagnostics.
Product Parameters
|
Model
|
BCT-UU 48-200
BCT-UU 48-250
BCT-UU 48-300
|
|
|
Basic
Specifications
|
Nominal Capacity
|
200Ah/250Ah/300Ah
|
|
Nominal Voltage
|
48V (51.2V)
|
|
|
Electricity (kWh)
|
10.24kWh
12.8kWh 15.36kWh |
|
|
Input
|
Full Charge Voltage
|
58.4V
|
|
Maximum Charging Voltage
|
60V
|
|
|
Input Voltage Range
|
58V-60V
|
|
|
Continuously Use Input Current
|
120A
|
|
|
Maximum Solar Panel Input Current
|
120A
|
|
|
Rshoot Delay Protection
|
1000ms
|
|
|
Output
|
Continuously Use Output Current
|
120A
|
|
Discharge Cut-Off Voltage
|
44V-46V
|
|
|
Over-Discharge Delay Protection
|
1000ms
|
|
|
Short Circuit Protection Delay
|
300us
|
|
|
Short Circuit Protection Recovery
|
Disconnect Load
|
|
|
Instant Start Current
|
120A
|
|
|
Battery
|
Cell Type
|
LiFePO4 Battery/LFP
|
|
Storage Temperature Range
|
Short-Term -20℃-40℃ (Within 1 Month)
Long-Term 10℃-35℃ (Within 1 Year)
|
|
|
Operating Temperature Range
|
-15℃-60℃
|
|
|
Recommended Temperature Range
|
10℃-40℃
|
|
|
Storage Humidity
|
≤75％ RH
|
|
|
Atmospheric Pressure
|
Below the elevation of 5000m
|
|
|
Self-Discharge ( 25°C)
|
＜3％/Month
|
|
|
Depth Of Discharge
|
＞80％
|
|
|
C-rate Discharge
|
＜0.8C
|
|
|
Cycle Life
|
＞6000 times (＜0.5C)
|
|
|
Other
|
Certification Standards
|
UN38.3/CE/MSDS
|
|
Warranty
|
10 years
|
|
|
Product Size
|
798±2×565±2×401±2mm
|
|
|
Packing Size
|
903±2×671±2×451±2mm
|
|
