Product Overview
The 48V solar energy storage lithium iron phosphate battery pack is a reliable and environmentally friendly alternative for solar energy storage. This product has been engineered to have a high cycle life and low self-discharge rate, thus minimising maintenance requirements and providing a stable power supply for your solar system. The product's compact and lightweight design facilitates easy installation, making it an excellent choice for residential and small-scale solar installations.
Empowering Clean & Reliable Home Energy
- In areas without electricity, it can be charged by solar panels during the day, and its stored electricity can be used at night to provide electricity for lighting or other appliances.
- In areas where the electricity price is high, this product can be used to store electricity during valley hours for the use of electricity at peak hours.
- Easy to install; energy-saving and environmentally friendly; can reduce the electricity costs; long service life.
- Storing the power from the solar panel to be used as a reserve power or emergency power supply.
- At night or at the time of a power outage, it can supply power to electrical appliances by using the stored energy, to avoid the inconvenience caused by a power outage, so that you can calmly deal with the situation of a power outage.
We are a photovoltaic new energy enterprise, possessing the corresponding full range of qualification certifications. Product quality is guaranteed, enabling customers to use it with confidence. Clean energy for modern living. Bring modern energy to your everyday life - with safety and sustainability at its core.
The system has been constructed using premium components, ensuring that it reliably meets the daily electricity needs of most households. It has been designed for durability, safety, and consistent performance.
Planning a bulk import? Fill out our quick inquiry (qty, delivery port, target date) and our export team will respond within 24 hours.
|
Model
|
BCT-UU 48-200
BCT-UU 48-250
BCT-UU 48-300
|
|
|
Basic
Specifications
|
Nominal Capacity
|
200Ah/250Ah/300Ah
|
|
Nominal Voltage
|
48V (51.2V)
|
|
|
Electricity (kWh)
|
10.24kWh
12.8kWh 15.36kWh |
|
|
Input
|
Full Charge Voltage
|
58.4V
|
|
Maximum Charging Voltage
|
60V
|
|
|
Input Voltage Range
|
58V-60V
|
|
|
Continuously Use Input Current
|
120A
|
|
|
Maximum Solar Panel Input Current
|
120A
|
|
|
Rshoot Delay Protection
|
1000ms
|
|
|
Output
|
Continuously Use Output Current
|
120A
|
|
Discharge Cut-Off Voltage
|
44V-46V
|
|
|
Over-Discharge Delay Protection
|
1000ms
|
|
|
Short Circuit Protection Delay
|
300us
|
|
|
Short Circuit Protection Recovery
|
Disconnect Load
|
|
|
Instant Start Current
|
120A
|
|
|
Battery
|
Cell Type
|
LiFePO4 Battery/LFP
|
|
Storage Temperature Range
|
Short-Term -20℃-40℃ (Within 1 Month)
Long-Term 10℃-35℃ (Within 1 Year)
|
|
|
Operating Temperature Range
|
-15℃-60℃
|
|
|
Recommended Temperature Range
|
10℃-40℃
|
|
|
Storage Humidity
|
≤75％ RH
|
|
|
Atmospheric Pressure
|
Below the elevation of 5000m
|
|
|
Self-Discharge ( 25°C)
|
＜3％/Month
|
|
|
Depth Of Discharge
|
＞80％
|
|
|
C-rate Discharge
|
＜0.8C
|
|
|
Cycle Life
|
＞6000 times (＜0.5C)
|
|
|
Other
|
Certification Standards
|
UN38.3/CE/MSDS/DGM
|
|
Warranty
|
10 years
|
|
|
Product Size
|
798±2×565±2×401±2mm
|
|
|
Packing Size
|
903±2×671±2×451±2mm
|
|
