Products Features
6kW SINGLE PHASE SOLAR INVERTER
Versatile All-in-One Design
Combines MPPT solar charge controller, high-frequency pure sine wave inverter, and UPS functionality, perfect for Hybrid Inverters backup power and self-consumption applications.
5-Year Warranty
Backed by a 5-year warranty, ensuring reliable after-sales service and product support.
High Performance & Efficiency
Delivers up to 6kW power output with a wide MPPT range of 120-450V and 500Voc for optimal solar energy conversion.
Flexible Battery Compatibility
Can operate with or without a battery, providing flexible energy solutions for various setups.
Scalable & Versatile
Features dual AC outputs, supports both solar and grid power supply.
Smart Monitoring & Battery Support
Includes a 100A built-in solar charger, lithium battery activation, and optional WiFi/GPRS remote monitoring for real-time control and management.
Products Details
- High-Efficiency MPPT – MPPT range of 120V~450V, supports 500Voc, delivers pure sine wave AC output, and operates without a battery.
- Dual Power Supply – Supports simultaneous power supply from solar and grid with multiple interfaces for flexible and reliable connections.
- Smart Communication – Built-in CAN/RS485 ports for seamless BMS integration, with optional WiFi/GPRS remote monitoring.
- Easy Maintenance – Features a removable dust cover for durability and effortless upkeep.
| AC INPUT | |
| Rated Input Voltage(VAC) | 208/220/230/240;L+N+PE |
| Voltage Range(VAC) | 90~280±3(normal mode);170~280±3(UPS mode) |
| Frequency(Hz) | 50/60(Auto Adaptive) |
| AC OUTPUT | |
| Voltage(VAC) | 208/220/230/240 |
| Frequency | 50/60Hz±0.1% |
| Wave Form | Pure Sine Wave |
| CHARGER(PV/AC) | |
| Solar Charger Type | MPPT |
| Max PV Input Current /Input Power | 18A/6000W |
| MPPT Range@Operating Voltage(VDC) | 120~450 |
| BATTERY | |
| Rated Voltage(VDC) | 48 |
| Battery Type | Lithium and Lead-acid |
| INTERFACE | |
| Interface | RS485/RS232/USB/Dry Contact |
| Monitoring | WiFi(Opptional) |
Products Information
Solar System Connection
Maximum power 6kW, power factor 1. equipped with CAN/RS485 for BMS communication. MPPT range 120V~ 450V, 500Voc, can work without batteries. high frequency inverter: small size, light weight. WIFI/GPRS remote monitoring (optional), pure sine wave AC output, dual AC output, solar energy and utility grid can simultaneously power the load, feed into the grid.
